Gold Reader

UHF RFID HANDHELD READER

Features:
– 865-868MHz (ETSI)
– 33 dBm (Software adjustable)
– Power over Ethernet (option)
– Communication via LLRP
– LLRP READER: Windows 7+, Linux
– LLRP TOOLKIT: C,C++,JAVA

– Certificated for: CE, UK CA



Applications:

– Logistic tracking
– Inventory management
– Sport timing

Product Overview

The Gold Reader is a simple fixed low profile reader with 33dBm power output that enables users to start reading tags and developing solutions immediately.



Gold Reader communicates via Low Level Reader Protocol.



LLRP ToolKit enables easy development of custom interfaces to control the reader if desired. The user friendly LLRP READER software enables the user to begin solution development immediately.



 The combination of this capability with up to 4 antenna signifi cantly reduces the cost and complexity of installing an RFID read point.

Technical Specification

High Performance 4-Port UHF RFID reader

Air Interface Protocol: EPCglobal UHF Class 1 Gen 2
Frequency: 865 – 868Mhz
Number of Channels: 4 channels
Supported Region: ETSI (Europe) – ETSI EN 302 208
RF Power Output: 33dBm
Max. Receiver Sensitivity: -75dBm
Antenna Ports: 4 x straight SMA-F, 50 ohm
Ethernet Interface: 10/100 Base-T
Auxiliary Interfaces:
USB 2.0 connectivity
It appears as USB serial port
USB type B connector
RS232 TTL level

GPIOs:
4 x optically isolated inputs
4 x optically isolated outputs
GPIO connector: CANNON 15-pins 3-rows
Application Interface: Low Level Reader Protocol ver. 1.1

Power supply:
9V / 4A, DC power jack 2,1-2,5 mm
Operating Temperature: -20°C to +40°C
Dimensions: 215mm L x 150mm W x 35mm
Weight: 1,2 kg
